### F3 Pro Specifications
– **Motor Power:**
– Nominal: 750W x 2
– Peak: 1000W x 2
– **Battery:**
– **Capacity:** 48V, 40AH (1920Wh)
– **Top Speed:**
– **Class 1/2:** 20 MPH
– **Class 3:** 28 MPH
– **Off-Road:** Available in Off-Road Mode
– **Riding Range:**
– **Eco Mode:** 75 miles
– **Standard Mode:** 50 miles
– **Sports Mode:** 40 miles
– **Tires:** 20” x 4″ with inner tubes
– **Weight:** 45 kg (99 lbs)
– **Max Load:** 180 kg (400 lbs)
– **Package Weight:** 50 kg (110 lbs), dimensions 144x34x87 cm
– **Transmission Gears:** Single Gear
– **Brakes:**
– **Type:** Hydraulic (Front & Rear)
– **Brake System:** Dual Piston
– **Disc Size:** 180 mm
– **Lights:** Headlight, Tail warning light
– **Recommended Height:** 5’3″ – 6’4″ (160 cm – 195 cm)
– **Frame Material:** High-strength Steel Pipe
—
### F3 Pro Max Specifications
– **Motor Power:**
– Nominal: 750W x 2
– Peak: 1000W x 2
– **Battery:**
– **Capacity:** 48V, 55AH (2640Wh)
– **Top Speed:**
– **Class 1/2:** 20 MPH
– **Class 3:** 28 MPH
– **Off-Road:** Available in Off-Road Mode
– **Riding Range:**
– **Eco Mode:** 103 miles
– **Standard Mode:** 70 miles
– **Sports Mode:** 55 miles
– **Tires:** 20” x 4″ with inner tubes
– **Weight:** 49 kg (108 lbs)
– **Max Load:** 180 kg (400 lbs)
– **Package Weight:** 54 kg (119 lbs), dimensions 144x34x87 cm
– **Transmission Gears:** Single Gear
– **Brakes:**
– **Type:** Hydraulic (Front & Rear)
– **Brake System:** Four-Piston
– **Disc Size:** 180 mm (Front), 203 mm (Rear)
– **Lights:** Headlight, Tail warning light
– **Recommended Height:** 5’3″ – 6’4″ (160 cm – 195 cm)
– **Frame Material:** High-strength Steel Pipe
—
### Key Difference
The main distinction between the **F3 Pro** and the **F3 Pro Max** is their braking systems. The F3 Pro Max features a more advanced four-piston brake system with larger 203 mm discs, offering superior braking performance and stopping power compared to the F3 Pro’s dual-piston system with 180 mm discs.
A. Handlebar Length: 28.3″/ 72cm
B. Total Length: 67.7″/ 172cm
C. Total Height: 44.1″/ 112cm
D. Seat Length: 18.9″/ 48cm
E. Top Tube Length: 35.8″/ 91cm
F. Tire Width: 4″/ 10cm
G. Wheel Diameter: 21.7″/ 55cm
H. Seat to Ground Height: 33.5″/ 85cm
I. Wheelbase: 45.3″/ 115cm
J. Seat Height from Tire: 8.7″/ 22cm
K. Head Tube Length: 24.4″/ 62cm
L. Battery Length: 13.8″/ 35cm
*Manual measurement, there is 0-3 cm error.
1. 20″*4 fat tires*2
2. 20Ah Battery+35Ah Battery
3. Charger*2
4. Adjustable phone holder
5. Fenders
6. Pedals*2
7. Front light
8. Bicycle frame
9. Owner’s manual
Motor
Off-road Mode (Dual motor + Full power):
Unleash the full potential of our dual-motor setup and zoom away at exhilarating speeds of up to 34mph! Just switch to PAS level 5, and feel the rush of rapid acceleration under full throttle. Perfect for those who love a thrilling, high-speed adventure.
Battery
Battery | 1,920Wh & 2,640Wh
Model F3 Pro: 1,920Wh (48V, 20Ah & 20Ah)
Model F3 Pro Max: 2,640Wh (48V, 20Ah & 35Ah)
Charge Time | 7-10 hours
Charging hours depend on how much Battery energy you already used. In the first 5 hours, the battery is charged quickly. After then, it will be charged slowly till it is full. To keep the battery safe and durable, we recommend to charge slowly, like 2Amp. Fast charging may shorten battery lifetime and even damage it.
Performance
Top Speed | Class 3, Off-road Mode
You can shift between Class 3 and Off-road mode.
Range | 40-100miles
Depends on Battery capacity and Ride mode selection.
ECO mode: Please enable Single motor and adjust PAS Level 2 to Keep your average speed at 15-20mph, you will obtain long range mode.
Model F3 Pro (40Ah battery): 44-75 miles.
Model F3 Pro Max (55Ah battery): 60-103 miles.
USB Charging Port
A USB data cable port is provided on the battery, so when we are riding outdoors and our phone doesn’t have enough power, we can plug it into our e-bike’s power USB port to charge our phone.
20” Inflatable Tire with Inner Tube
With huge 20″ x 4″ fat tires, explore pressing through obstacles and impacts to give your adventure a steady ride and a consistent speed.
High Intensity Headlight
Ride safe using the bright headlight with a unique LED circle that lightens up your way while also making you easily visible to others.
Multi-functional Display
Operating on the multi-function display, you can always find out important information such as odometer, speedometer, wattage, battery capacity, etc. provided by the digital display.
